Avacontrol-100
Z-Wave Cerntral Controller Gateway
( ODM Welcome )

English | Chinese

Z-Wave Central Controller SCC-100
Support Z-Wave Home Control Groups
  • Door Lock - Keypad
  • Whole Home Meter - Simple
  • Sub Energy Meter
  • Notification Sensors
  • Multilevel Sensors
  • Security Keypad
  • On/Off Switch, Power Strip
  • Light Dimmer Switch, Fan Switch
  • Window Covering
  • Thermostat, HVAC
  • Thermostat, Setback
  • Alarm
  • Valve, Open/Closed

Product Description
The avaControl-100 is a fully equipped Z-Wave Internet Gateway.


Avadesign Avacontrol-100 is a consumer electronics device used for home automation. Avacontrol-100 gateway communicates with electronic sensors and devices located throughout home using wireless and wired communications and connects to central portal server using existing broadband connection (Cable or DSL).

USB Z-Wave module allows user to control Z-Wave sensors, appliance controls and automation devices.
Avacontrol-100 integrates multiple complicated control, automation and internet protocols into one simple plug’n’play device. It provides a clear, consistent interface that allows user to manage home easily, whether at home, office or using mobile phone on the road.

The Avacontrol-100 controls switches, dimmers, motion s
ensors, temperature sensors and many more Z-Wave devices.


Click here for Video introduction Ultrahub Z-Wave Gateway

AvaControl-100 Hardware Specifications:
• Processor: CKVIUM ECONA CNS3410, 600MHZ
• Flash storage: 32 MB
• RAM Memory: DDR2 128 MB
• USB (Accessory) Ports: 2
• WAN (Internet) Ports: 1
• LAN (Local Network) Ports: 4
• Z-Wave USB Dongle ZU-1401 (Included)
• Dimensions (HxWxD): 155mm x 107mm x 30mm

Power Supply (Included) Specifications:
• Input: 100 ~ 240VAC , 50~60Hz
• Output: 12VDC/2A

Included Home Automation Functions:
  • Schedule setting
  • Sensor Trigger Event
  • Scene Control
  • Door Lock Control
  • Lighting Control

Support HTTP server to serve XML API
Help developers design unique home automation application.
Download Details of Middle ware API here




Stacks Image 1850
Stacks Image 41481
Stacks Image 41490
Stacks Image 41492
Stacks Image 41494
Stacks Image 41496

Installation Ultrahub -- How to install Z-wave Central Controller Gateway. ( avacontrol-100 )

Using the Ultrahub Part 1 ( Z-Wave gateway user operation )

Using the UltrahubPart 2 ( How to use Z-wave gateway control )
