MODBUS IO 控制器

具有RJ-45, RS485通信介面,網頁UI設定介面,具有多樣性的IO數位介面。12~24V電源輸入

  • MOD2012: 支援 8個 DI輸入及4個Relay數位輸出接口
  • MOD2016: 支援支援 8個 DI輸入及8個DO數位輸出接口
  • MOD2116: 支援 16個 DI輸入接口

MOD2012

Digital Input
Channels8
Input typeWet/Dry
Off voltage level1V
On voltage level3.5V ~ 24 V
CounterChannel:8
Max.Counts :32 Bit(4,294,967,295)
Max Input Frequency DI~DI8 :2KHz
Min. Pulse Width DI1~DI8: 500us
LED8 LEDs reflecting the DI pin status
Relay Output
Channels4
Relay typeSignal Relay Form A x 2, Form C x 2
Spec
Contact Rating0.6A @ 125 VAC, 2A@30 VDC
Min. Contact Load10 uA@ 10 mV
Contact MaterialGold-plated Silver
Operate Time3 ms
Release Time2 ms
Mechanical Endutance1 x 105ops.
Electronic Endurance5 x 10 5 ops.
Power
Input Voltage Range12V~48V DC(+- 10%)
Power ConsumptionMax 2.7W(24VDC)
Mechanism
InstallationDIN-Rail
Dimension115mmx110mmx30mm
Environment
Operating Temperature-25°C ~75°C
Storage Temperature-30°C~80°C
Relative Humidity10~90%, No Condensation
